 01.Power Supply >> CCTV Adaptor >> adaptor PKA12V1AU2 USA PLUG

  adaptor PKA12V1AU2 USA PLUG
Product Name:adaptor PKA12V1AU2 USA PLUG
Product S/N:112916263917
Specification:DC12V1A12W,CE&RoHS
Product Feature:CE&RoHS,PTC fuse,integrated power distribution unit
Product Class:01.Power Supply
Quality Rank:
Chat with us:Click to chat via msnClick to chat via skype
Email:Welcome to contact me for the CCTV power supply business!
    Product Description


Input:AC100-240V,
Output:DC12V 1A.
wall mount  adaptor.
overload protection
shortcircuilt protection
voltage regulated

ITEM

PKA12V1AU2

Description

12 V 1A DC

Input

Input AC plug

Optional

Input voltage

AC100-240V50/60Hz

Output

Output Connect ing plug :

5.5*2.1mm DC

Output voltage:

12V DC

Output electric current:

1000MA

R ipple wave :

(mVp-p): <1%

Linear modulate:

±0.5%max

Temperature coefficient:

±0.02%/℃

start time

≤1s(240V output,1o=100%)

guard time:

≥20ms(240V input,1o=100%)

Protection

override protection :

115% ~ 150% kvA , automatic recovery

overvoltage protection

30% ~ 150% V AC ,No recovery

short-circuit protection

1 channel : automatic recovery

Environment

working temperature :

0℃ ~ 40℃,10% ~ 90%RH

Store temperature :

-20℃ ~ 85℃,10% ~ 90%RH

ASL :

<3000m

Cooling:

Environment

Size

Size:

X X mm

weight:

G

Certificates:UL,CE,RoHS CE(EUC,EMC,LVD) EN 55022:2006+A1:2007
EN 61000-3-2:2006
EN 61000-3-3:2008
EN 55024:1998+A2:2003
EN 60950-1:2006
RoHS(EUT 2002/95/EC) EPA3050B:1996,EN1122:2001
EPA3052:1996,EPA3060A
EPA7196,EPA3540C,EPA8270C
